Fast Roll-Up Doors for Busy Loading Docks

High-speed dock doors are motorized vinyl doors that roll up quickly, opening at speeds of about 20 to 100 inches per second. They close automatically after use, locking out cold, heat, dust, and pests while letting forklifts move through without delays.

20 to 100 in./secOpening speed
100+ cycles a dayRated use
Up to 25 x 20 ft.Custom sizes
$4,350 to $21,093Typical price
14 to 25 daysMost orders ship
1-year limitedWarranty

Request a Quote

A high-performance fabric roll-up door installed at an industrial or commercial facility entrance.

Why Busy Docks Switch to High Speed Doors

A slow door can disrupt work because it is mostly left open by drivers. For instance, if it requires 15 seconds for a door to open, and a driver pass through it 40 times within an hour, workers can leave such door open to save time. However, once the door is open, it cannot lock out dust, weather, or outside air.

A high-speed door opens in time as the forklift approaches and closes immediately after it passes. This way, workers can move efficiently while keeping the opening closed when it’s not in use.

Reduces heat and cooling loss
Keeps indoor air cleaner
Prevents forklifts from waiting in line at the loading bay

Good To Know: You can also call these doors rapid roll doors, fast-acting doors, or high-performance doors. All these names describe a fabric door with a fast motor designed to open and close from time to time. Explore the speed and sizes available on our high-speed roll-up doors page.

Choose Your Speed

Choose a door speed according to how you intend to use it. We design every model to handle at least 100 or more cycles per day.

Standard20 in./secIt’s a cost-effective option for loading docks with regular traffic
Fast30 in./secA good option for busy docks with up to 500 cycles daily
Rapid100 in./secDesigned for forklift lanes with frequent traffic, handling up to 500 cycles daily

Tip: If you open the door a few times a day, a manual vinyl roll-up door or a motorized door at 12 in. per second are cost-effective options that meet your needs.

A high-speed roll-up dock door shown fully open at a loading dock, allowing clear passage for vehicles and freight.

What Comes Standard

We ship every door as a complete kit customized to fit your opening. In the kit, you will find the following components:

Tear-resistant 22 oz. vinyl curtain, with an optional upgrade to 40 oz. vinyl.
Full-width clear vision panel, so drivers can see through the door
Breakaway bottom bar with automatic reset, so a forklift hit does not tear the door
Replaceable aluminum side tracks in 2, 4, or 6 in. depths
Three-position wall switch
Forest green, blue, black, or yellow curtain, with other colors at extra cost

Good To Know: We ship most replacement parts within one or two days.

High Speed vs Standard Roll-Up Doors

	High Speed Door	Standard Roll-Up Door
Opening speed	20 to 100 in. per second	About 12 in. per second, or by hand
Closes on its own	Yes	Usually no
Daily use	100 or more cycles a day	Low-use openings
Keeps drafts and dust out	Yes, it stays shut	Often left open
Price	About $4,350 to $21,093	Lower
Best for	Busy docks and high-traffic inside openings	Quiet openings and tight budgets

The Takeaway: Choose a faster door where there is high traffic. The speed will save time and reduce energy loss if the door opens frequently within an hour. We recommend a standard model for doors that open only a few times daily.

Mounting and Installation

A high-traffic roll-up door installed at an industrial facility entrance handling frequent forklift and pedestrian access.

Works With Your Existing Dock Door

Many loading docks keep their existing steel doors for security at night and install high-speed doors for faster movement during the day. There are four mounting ways for this dock door:

Header MountYou install the door inside the opening
E-Track MountAllows you to fit the door over an existing steel door
Stand-Off MountThe door is fitted over the opening
Wall MountOver the opening

Ships as a kit with every part you need
Most installs take 3 to 10 hours with basic tools, plus a lift for larger doors
Plan on 6 to 18 in. of headroom, depending on the door

A high-speed roll-up door at an industrial facility opening used for dust control between work areas.

Options and Controls

Choose how the door opens so there’s no need for drivers to always push a button.

How It Opens

Motion sensors that detect when a cart or forklift is approaching and automatically open the door
Pull cords that hang 3 to 5 ft. from the door, making it easy for drivers to activate it while seated
Floor loop sensors installed into the concrete for detecting metal carts and forklifts to trigger the door to open
Remote controls you can hold in your hands or mount on a forklift for operating the door
Keypads that use an entry code to give you access to restricted areas

Safety, Weather and Power

Safety edges that reverse the door when they detect an obstruction, NEMA 4-rated controls, and protective hoods.
Fiberglass wind bars or aluminum hinges for windy exterior docks
240V, 480V, three-phase and watertight motors

Frequently Asked Questions about High Speed Dock Doors

How much does a high-speed roll up door cost?

The cost of our high-speed roll-up doors ranges from $4,350 to $21,093. The prices are mainly determined by size, followed by the speed, vinyl weight, motor voltage, controls, and safety options. Send us your opening requirements to get a precise quote.

What is a rapid roll door?

A rapid roll door is a fabric roll-up door with a fast motor, engineered to open many times daily. Our model operates at 20, 30, or 100 inches per second right after use. This helps the door close between deliveries and other movements.

How fast do high speed dock doors open?

Our standard high-speed dock door model opens at 20 inches per second, while the rapid model opens at 100. For comparison, a standard motorized vinyl door moves at about 12 inches per second.

Can a high speed door go on an exterior loading dock?

Yes, a high-speed door can go on an exterior loading dock. For outdoor loading docks, you can add fiberglass wind bars or aluminum hinges to help the door handle strong winds. Many docks also keep a steel door in place to lock up at night.

Can I add a high speed door to a dock that already has a steel door?

Yes, you can add a high-speed door to a dock that already has a steel door. You can fit the high-speed door over your existing steel door with an E-track or stand-off mount. The steel door locks the dock at night, while the fast door allows easy movement during the day.

What is the difference between a dock door and a grade-level door?

The difference between a dock door and a grade-level door is that you install a dock door on a raised loading dock that has the same height as a truck bed, allowing forklifts to drive through into the trailer. A grade-level door, on the other hand, is installed at the ground level. Depending on your choice, you can use high-speed doors in both cases.

How long does it take to get a high speed dock door?

We ship most orders in 14 to 25 days. You will find your shipping date on your quote. We design each door to fit your opening, and they ship as a complete kit.

High Speed Dock Door Specs

High speed roll-up door installed at an industrial loading bay dock for fast vehicle and forklift access.

Open speed of 20, 30, or 100 in. per second
Designed for at least 100 or more cycles a day, rapid models handle up to 500 cycles a day.
Comes with up to 25 ft. wide x 20 ft. high custom sizes
22 oz. vinyl stays flexible to -30°F, and 40 oz. vinyl to -40°F
Compatible with foot, cart, and forklift traffic
Comes with a one-year limited warranty on parts and workmanship
We ship most orders within 14 to 25 days
